Lenze · E94AYCET communication module (EtherCAT®) · Communication Manual · DMS 9.0 EN · 02/2014 · TD17
125
13 Parameter reference
13.3 Parameters of the communication module for slot MXI2
_ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _
C14850
C14851
C14852
Parameter | Name:
C14850 | All words to master
Data type: UNSIGNED_16
Index: 9725 = 0x25FD
Display of the process data words (subcodes 1 ... 32) which are transferred from the communication module to the
master.
Only those which are configured are valid.
Display area
(min. value | unit | max. value)
0 65535
Subcodes Info
C14850/1
...
C14850/32
 Read access  Write access  CINH  PLC-STOP  No transfer  PDO_MAP_RX  PDO_MAP_TX  COM  MOT
Parameter | Name:
C14851 | All words from master
Data type: UNSIGNED_16
Index: 9724 = 0x25FC
Display of the process data words (subcodes 1 ... 32) which are transferred from the master to the communication
module.
Only those which are configured are valid.
Display area
(min. value | unit | max. value)
0 65535
Subcodes Info
C14851/1
...
C14851/32
 Read access  Write access  CINH  PLC-STOP  No transfer  PDO_MAP_RX  PDO_MAP_TX  COM  MOT
Parameter | Name:
C14852 | All words to standard device
Data type: UNSIGNED_16
Index: 9723 = 0x25FB
Display of the process data words (subcodes 1 ... 32) which are transferred from the communication module to the
standard device.
Display area
(min. value | unit | max. value)
0 65535
Subcodes Info
C14852/1
...
C14852/32
 Read access  Write access  CINH  PLC-STOP  No transfer  PDO_MAP_RX  PDO_MAP_TX  COM  MOT
