6 Appendix: Code description
Table 1: Monitor state
Table 2: Colour coding
See also the separate "Safety-at-Work" monitor documentation for a descrip-
tion of the codes used for monitor state, OSSD state, device colours and
assignments to OSSDs.
Monitor state
Code significance
0 protective mode, everything OK (output circuits that are not installed, not
configured or dependent output circuits are indicated as OK)
1 protective mode, output circuit 1 off.
2 protective mode, output circuit 2 off
3 protective mode, both output circuits off.
4 configuration mode: power on
5 configuration mode
6 reserved / not defined
7 configuration mode: fatal device error, RESET or device replacement
necessary
Colour coding
Code colour meanining
0 green block is in the ON state (switched on)
1 green flashing block is in the ON state (switched on), but already in the
transition to the OFF state, e.g. shutdown delay
2 yellow block is ready, but is still waiting for a further condition,
e.g. local acknowledgement or Start button
3 yellow
flashing time condition exceeded, action must be repeated, e.g.
synchronization time exceeded
4 red block is in the OFF state (switched off)
5 red flashing the error interlock is active, clear using one the following
actions:
> Acknowledge using the ESC/Service button
> Power OFF/ON
> AS-i OFF/ON
6 grey OSSD not used / no communication with the AS-i slave
