Page 28
AS-i 3.0 Command Interface
Commands of the Command Interface
Subject to reasonable modifications due to technical advances
Id.-No.: 102875 Issue date - 3.12.2007
EUCHNER GmbH + Co. KG
Kohlhammerstraße 16, D-70771 Leinfelden-Echterdingen
Tel. +49/711/7597-0, Fax +49/711/753316
28
4.3.3.12
Command 14: "Diagnosis / shutdown-history"
With this command the "diagnosis / shutdown-history" can be read separate for
each release circuit.
133
device colour 95
134
device index 32
135
assignment
5
of the device 32 to the OSSD
...
260
device index 95
261
assignment of the device 95 to the OSSD
1. For code description see table "Monitor state", page 94
2. By means of device colours it is possible to form an opinion about the state of the OSSDs (see table "Colour coding", page 94)
3. The maximal value is 7, higher values are limited to 7
4. By means of device colours it is possible to form an opinion about the state of the OSSDs (see table "Colour coding", page 94)
5. For assignment of the devices to the OSSD see table "Allocation", page 95
Request buffer
Byte
2
7
2
6
2
5
2
4
2
3
2
2
2
1
2
0
1
list selection (0=current diagnosis; >0=diagnosis by OSSD turning-off
(past events memory)
2
number of the OSSD (0=preprocessing)
3
Fdiagnosis format
(0=comlete diagnosis; 1=sorted according to the diagnosis index)
Response buffer
Byte
2
7
2
6
2
5
2
4
2
3
2
2
2
1
2
0
1
response type (0=device colour; >0=reserved)
2
monitor state; byte 1 (see table "Monitor state", page 29 for description)
3
OSSD type (0=internal OSSD; 1=peripheral OSSD)
4
OSSD info
- OSSD number, if internal OSSD (0=preprocessing, 1=OSSD 1,
2=OSSD 2);
- Slave address, if peripheral OSSD (address 0 – 63, bit 7 points at the
AS-i circuit that is allocated to the AS-i slave; 0=circuit 1, 1=circuit 2)
5
OSSD state (Bit 0-bit 3 colour of the OSSD; bit 4-bit 7 reserved)
6
colour device 0 (description see table "State and colour coding", page
29).
...
...
261
colour device 255
Response buffer
Byte
2
7
2
6
2
5
2
4
2
3
2
2
2
1
2
0
