background image

AS-i 3.0 Command Interface

Command Interface Examples

Subject to reasonable modifications due to technical advances

Id.-No.: 102875 Issue date - 3.12.2007

EUCHNER GmbH + Co. KG

Kohlhammerstraße 16, D-70771 Leinfelden-Echterdingen

Tel. +49/711/7597-0, Fax +49/711/753316

75

5

Command Interface Examples

5.1

Reading 16-bit input values

Command RD_7X_IN: Reading of 16-bit input values.

Meaning of the bytes:

The call of the command interaface has not been answered with the valid values
since the toggle bit has not been set.

Set of toggle bit:

PROFIBUS:
PROFIBUS DP V0: cyclic data exchange
Used ID/module in the GSD file: 12-byte management

Request: RD_7X_IN

Byte 1

50

hex

(RD_7X_IN)

Byte 2

00

hex

(master 1, single master)

Byte 3

1D

hex

(slave address 29)

Byte 4

00

hex

Byte 12

00

hex

Response

Byte 1

00

hex

(or old values)

Byte 2

00

hex

(or old values)

Byte 3

00

hex

(or old values)

Byte 4

00

hex

(or old values)

Byte 12

00

hex

(or old values)

Request

Byte 1

50

hex

Byte 2

80

hex

(toggle bit, result)

Byte 3

1D

hex

(slave address 29)

Byte 4

00

hex

Byte 12

00

hex
