4. Read response (data part 2):
response
byte 1 0x4F (RD_ACYC_TRANS)
byte 2 0x00 (OK)
byte 3 0x0A (safety monitor diagnostics)
byte 4 0x01 (length of the response buffer high)
byte 5 0x06 (length of the response buffer low) 262
byte 6 0x00 (fixed)
byte 7 state of monitor
byte 8 state of OSSD1
byte 9 state of OSSD2
byte 10 number of devices "not-green"
byte 11 reserved
byte 12 0x20 (device index 32)
byte 13 device colour 32
byte 14 0x21 (device index 33)
byte 15 device colour 33
...
byte 36 0x2C (device index 44)
byte 37 device colour 44
byte 38 0x2D (device index 45)
request
byte 1 0x4F (RD_ACYC_TRANS)
byte 2 0x00 (master 1)
byte 3 0x00 (integrated safety monitor)
byte 4 0x00 (puffer index high)
byte 5 0x24 (puffer index low) 36
response
byte 1 0x4F (RD_ACYC_TRANS)
byte 2 0x00 (OK)
byte 3 device colour 45
byte 4 0x2E (device index 46)
byte 5 device colour 46
...
byte 36 0x3E (device index 62)
byte 37 device colour 62
byte 38 0x3F (device index 63)
