AS-i 3.0 Command Interface
Commands of the Command Interface
Subject to reasonable modifications due to technical advances
Id.-No.: 102875 Issue date - 3.12.2007
EUCHNER GmbH + Co. KG
Kohlhammerstraße 16, D-70771 Leinfelden-Echterdingen
Tel. +49/711/7597-0, Fax +49/711/753316
24
4.3.3.6
Command 5: „Transfer S-7.5“
With this call the transfer string of a slave according to profile S-7.5 can be tras-
ferred. The request/response buffer contain the S-7.5 strings in the same form as
they are transferred via AS-i.
4.3.3.7
Command 6: Read „Cyclical S-7.5 16-bit configuration“
With this call the cyclical S-7.5 16-bit configuration can be read, the analog/tran-
parent bits being deleted in the response.
The cyclical 16-bit configuration cannot be determined if the response is 08
16
.
4.3.3.8
Command 7: Read „Safety Monitor sorted acc. to OSSD“
With this command the safety monitor is being read sorted acc. to the OSSD.
Request buffer
Byte
2
7
2
6
2
5
2
4
2
3
2
2
2
1
2
0
1
CTT2 command byte (16
10
- 19
10
)
2
index
3
length
4
data 0
5
data 1
...
...
n
data n-4
Response buffer
Byte
2
7
2
6
2
5
2
4
2
3
2
2
2
1
2
0
1
CTT2 reponse byte (50
10
- 52
10
, 90
10
- 92
10
)
2
data 0
3
data 1
...
...
n
data n-2
Response buffer
Byte
2
7
2
6
2
5
2
4
2
3
2
2
2
1
2
0
1
0
0: no output
1: 1-byte output
2: 1-word output
3: 2-word output
4: 3-word output
5: 4-word output
0: data
are
valid
1: data
are not
valid
0: no input
1: 1-byte input
2: 1-word input
3: 2-word input
4: 3-word input
5: 4-word input
Response buffer
Byte
2
7
2
6
2
5
2
4
2
3
2
2
2
1
2
0
0
00
16
1
monitor state
