10.Read response (data part 8):
request
byte 1 0x4F (RD_ACYC_TRANS)
byte 2 0x00 (master 1)
byte 3 0x00 (integrated safety monitor)
byte 4 0x00 (puffer index high)
byte 5 0xFC (puffer index low) 252
response
byte 1 0x4F (RD_ACYC_TRANS)
byte 2 0x00 (OK)
byte 3 device alocation 89
byte 4 0x5A (device index 90)
byte 5 device alocation 90
byte 6 0x5B (device index 91)
byte 7 device alocation 91
byte 8 0x5C device index 92)
byte 9 device alocation 92
byte 10 0x5D (device index 93)
byte 11 device alocation 93
byte 12 0x5E (device index 94)
byte 13 device alocation 94
byte 14 0x5F (device index 95)
byte 15 device alocation 95
