Setting the toggle bit:

The master has now been ordered to switch to protected mode.

6. Wait until master is in normal (protected) operation mode

Read out the flags, until the NA (Normal Operation Active) has been set.

No result because toggle bit = 0.

Request: SET_OP_MODE

Byte 1

0C

hex

(SET_OP_MODE)

Byte 2

80

hex

(T = 1, master 1, single master)

Byte 3

00

hex

(= protected mode)

Byte 4

00

hex

Byte 12

00

hex

Response

Byte 1

0C

hex

Byte 2

80

hex

(T = 1, result = 0)

Byte 3

00

hex

(or old values)

Byte 12

00

hex

(or old values)

Request: GET_FLAGS

Byte 1

47

hex

(GET_FLAGS)

Byte 2

00

hex

(T = 0, master 1, single master)

Byte 3

00

hex

Byte 12

00

hex

Response

Byte 1

00

hex

(or old values)

Byte 2

00

hex

(or old values)

Byte 12

00

hex

(or old values)
