AS-i 3.0 Command Interface Command Interface Examples
Subject to reasonable modifications due to technical advances Id.-No.: 102875 Issue date - 3.12.2007 EUCHNER GmbH + Co. KG
Kohlhammerstraße 16, D-70771 Leinfelden-Echterdingen Tel. +49/711/7597-0, Fax +49/711/753316
92
8. Read response (data part 6):
9. read response (data part 7):
request
byte 1 0x4F (RD_ACYC_TRANS)
byte 2 0x00 (Master 1)
byte 3 0x00 (integrated safety monitor)
byte 4 0x00 (puffer index high)
byte 5 0xB4 (puffer index low) 180
response
byte 1 0x4F (RD_ACYC_TRANS)
byte 2 0x00 (OK)
byte 3 device alocation 53
byte 4 0x36 (device index 54)
byte 5 device alocation 54
...
byte 36 0x46 (device index 70)
byte 37 device alocation 70
byte 38 0x47 (device index 71)
request
byte 1 0x4F (RD_ACYC_TRANS)
byte 2 0x00 (master 1)
byte 3 0x00 (integrated safety monitor)
byte 4 0x00 (puffer index high)
byte 5 0xD8 (puffer index low) 216
response
byte 1 0x4F (RD_ACYC_TRANS)
byte 2 0x00 (OK)
byte 3 device alocation 71
byte 4 0x48 (device index 72)
byte 5 device alocation 72
...
byte 36 0x58 (device index 88)
byte 37 device alocation 88
byte 38 0x59 (device index 89)
