EUCHNER AS-i 3.0 Command Interface User Manual
Page 8

AS-i 3.0 Command Interface
Structure of the Command Interface
Subject to reasonable modifications due to technical advances
Id.-No.: 102875 Issue date - 3.12.2007
EUCHNER GmbH + Co. KG
Kohlhammerstraße 16, D-70771 Leinfelden-Echterdingen
Tel. +49/711/7597-0, Fax +49/711/753316
8
Result codes
Please note that possibly some controls can exchange the high and low byte
on the field bus with word orientated access to the command interface.
Name
Value
Description
OK
00
16
execution without fault
HI_NG
11
16
general fault
HI_OPCODE
12
16
illegal value in command
HI_LENGTH
13
16
length of the command interface is too short
1
1. The length of the command interface in the I/O-data area respectively the length of the DPV1 requests is too short
HI_ACCESS
14
16
no access right
EC_NG
21
16
general fault
EC_SND
22
16
slave (source addr) not detected
EC_SD0
23
16
slave 0 detected
EC_SD2
24
16
slave (target addr) not decteced
EC_DE
25
16
delete error
EC_SE
26
16
set error
EC_AT
27
16
address temporary
EC_ET
28
16
extended ID1 temporary
EC_RE
29
16
read (extended ID1) error
