EUCHNER AS-i 3.0 Command Interface User Manual
Page 82
AS-i 3.0 Command Interface
Command Interface Examples
Subject to reasonable modifications due to technical advances
Id.-No.: 102875 Issue date - 3.12.2007
EUCHNER GmbH + Co. KG
Kohlhammerstraße 16, D-70771 Leinfelden-Echterdingen
Tel. +49/711/7597-0, Fax +49/711/753316
82
No result because toggle bit = 0.
Set the toggle bit:
Request: SET_PCD
Byte 1
25
hex
(SET_PCD)
Byte 2
00
hex
(T = 0, master 1, single master)
Byte 3
04
hex
(slave address to write to master)
Byte 4
EF
hex
(ID + IO to configurate)
Byte 5
37
hex
(xID2 + xID1 to configurate)
Byte 6
00
hex
…
…
Byte 12
00
hex
Response
Byte 1
00
hex
(or old values)
Byte 2
00
hex
(or old values)
Byte 3
00
hex
(or old values)
Byte 4
00
hex
(or old values)
…
…
Byte 12
00
hex
(or old values)
Request: SET_PCD
Byte 1
0C
hex
(SET_PCD)
Byte 2
80
hex
(T = 1, master 1, single master)
Byte 3
04
hex
(slave address to write to master)
Byte 4
EF
hex
(ID + IO to configurate)
Byte 5
37
hex
(ID + IO to configurate)
Byte 6
00
hex
…
…
Byte 12
00
hex
Response
Byte 1
25
hex
Byte 2
80
hex
(T = 1, result = 0)
Byte 3
00
hex
(or old values)
Byte 4
00
hex
(or old values)
…
…
Byte 12
00
hex
(or old values)
