AS-i 3.0 Command Interface Commands of the Command Interface
Subject to reasonable modifications due to technical advances Id.-No.: 102875 Issue date - 3.12.2007 EUCHNER GmbH + Co. KG
Kohlhammerstraße 16, D-70771 Leinfelden-Echterdingen Tel. +49/711/7597-0, Fax +49/711/753316
52
Meaning of bit B:
B = 0 Single AS-i slave or A-slave
B = 1 B-slave
4.5.16 Write AS-i slave extended ID1 (WRITE_XID1)
With this call, the extended ID1 code of an AS-i slave with address "0" can be writ-
ten directly via the AS-i cable. The call is intended for diagnostic purposes and is
not required in the normal master mode.
The AS-i master passes the extended ID1 code on to the AS-i slave without any
plausibility check.
Response
byte
2
7
2
6
2
5
2
4
2
3
2
2
2
1
2
0
1 0D
16
2 T result
Request
byte 2 7 2 6 2 5 2 4 2 3 2 2 2 1 2 0
1 3F
16
2 T – circuit
3 – xID1
Response
Byte
2 7 2 6 2 5 2 4 2 3 2 2 2 1 2 0
1 3F
16
2 T result
