AS-i 3.0 Command Interface List of all Commands
Subject to reasonable modifications due to technical advances Id.-No.: 102875 Issue date - 3.12.2007 EUCHNER GmbH + Co. KG
Kohlhammerstraße 16, D-70771 Leinfelden-Echterdingen Tel. +49/711/7597-0, Fax +49/711/753316
10
! page 42 READ_DUPLICATE_ADDR 2 11
16 read list of duplicate addresses 2 10
page 43 Configuration of AS-i Master
page 43 SET_OP_MODE 0C
16
set Operation_Mode 3 2
page 44 STORE_CDI 07
16 store Actual_Configuration 2 2
page 45 READ_CDI 28
16 read Actual_Configuration 3 4
page 45 SET_PCD 25
16
set Permanent_Config 5 2
page 45 GET_PCD 26
16
get Permanent_Config 3 4
page 47 SET_LPS 29
16 set LPS 11 2
page 48 GET_LPS 44
16 get LPS 2 10
page 48 STORE_PI 04
16
store Actual_Parameter 2 2
page 49 WRITE_P 02
16 write Parameter 4 3
page 49 READ_PI 03
16 read Parameter 3 3
page 50 SET_PP 43
16
set Permanent_Parameter 4 2
page 50 GET_PP 01
16 get Permanent_Parameter 3 3
page 51 SET_AAE 0B
16 set Auto_Address_Enable 3 2
page 53 SLAVE_ADDR 0D
16 change Slave_Address 4 2
page 52 WRITE_XID1 3F
16
write Extended_ID-Code_1 3 2
page 53 Other commands
page 53 IDLE 00
16 no request 2 2
page 54 READ_IDI 41
16
read IDI 2 36
page 54 WRITE_ODI 42
16 write ODI 34 2
page 55 READ_ODI 56
16 read ODI 2 34
page 55 SET_OFFLINE 0A
16
set Off-Line_Mode 3 2
page 56 SET_DATA_EX 48
16 set Data_Exchange_Active 3 2
! page 56 REWRITE_DPRAM 3 78
16
rewrite DPRAM 3 3
page 56 BUTTONS 75
16 disable push buttons 3 2
page 57 FP_PARAM 7D
16
functional Profile Parameter ≥3 ≥2
page 72 language-select 0E
16 set display language 4 3
page 73
replacement of safety
slaves input data
0F
16
set safety input slave "interpretation
data"
4 2
page 58 FP_DATA 7E
16 functional profile data ≥3 ≥2
page 62 "Safety at Work" list 00
16
slaves with released safety function,
response contains EcFlags
3 8
page 64 "Safety at Work" list 0D
16
slaves with released safety function,
response doesn‘t contain EcFlags
3 6
page 64
"Safety at Work" diagno-
sis
02
16 monitor diagnosis 5 n
page 70
integrated AS-i sensors:
Warnings
03
16 sensors with deleted D1 bit 3 10
Values for command
see page Command Value Meaning
Req
Len Res
Len
