AS-i 3.0 Command Interface
Commands of the Command Interface
Subject to reasonable modifications due to technical advances
Id.-No.: 102875 Issue date - 3.12.2007
EUCHNER GmbH + Co. KG
Kohlhammerstraße 16, D-70771 Leinfelden-Echterdingen
Tel. +49/711/7597-0, Fax +49/711/753316
26
4.3.3.9
Command 8: Read „Safety Monitor unsorted by OSSD“
With this command the safety monitor is being read unsorted by OSSD
Following assignment is possible:
00
16
: Preprocessing
01
16
: OSSD 1
02
16
: OSSD 2
03
16
: OSSD 1+2
80
16
: Device doesn‘t exist
4.3.3.10
Command 9: „reserved“
This command is reserved for future developments.
Response buffer
Byte
2
7
2
6
2
5
2
4
2
3
2
2
2
1
2
0
0
00
16
1
monitor state
2
OSSD 1 state
3
OSSD 2 state
4
number of not green
1
devices, OSSD 1
1. The maximal value is 7, higher values are limited to 7.
5
—
6
device index 32
7
device colour 32
8
device index 33
…
…
133
device colour 95
134
device index 32
135
assignment of the device 32 to the OSSD
…
…
261
assignment of the device 95 to the OSSD
See
the codes used for monitor state, OSSD state, device colours and assign-
ments to OSSDs and the "Safety-at-Work" monitor documentation.
