Monitor state
Bit [4 ... 0]
0 ... 31 reserved
Bit 5 configuration mode
0 monitor not in configuration mode
1 monitor in configuration mode
Bit 6 protected mode
0 monitor not in protected mode
1 monitor in protected mode
Bit 7 device error
0 no device error
1 fatal device error, RESET or device exchange required
State and colour coding
Bit [2 ... 0] State and/or colour coding
0 green permanent light
1 green flashing
2 yellow permanent light
3 yellow flashing
4 red permanent light
5 red flashing
6 grey and/or off
7 reserved
Bit [4 ... 3]
0 ... 3 reserved
Bit 5 modification
0 no device modification by "switch off"
1 device modification by "switch off"
Bit 6 existence
0 device exists
1 device doesn‘t exist
Bit 7 Usage
0 device is used in this OSSD
1 device is not used in this OSSD
