AS-i 3.0 Command Interface Commands of the Command Interface
Subject to reasonable modifications due to technical advances Id.-No.: 102875 Issue date - 3.12.2007 EUCHNER GmbH + Co. KG
Kohlhammerstraße 16, D-70771 Leinfelden-Echterdingen Tel. +49/711/7597-0, Fax +49/711/753316
70
4.7.5 Integrated AS-i Sensors: Warnings
(Function: 03
16
)
List of integrated AS-i sensors according to profile S-1.1 (without extended ad-
dressing) or profile S-3.A.1 (with extended addressing), by which the input data bit
D1 ("Warning") being deleted.
For creating of this list CDI and IDI are used only. Integrated AS-i slaves which are
projected but not existing therefore are not entered here.
See for a description of
the codes used for monitor state, OSSD state, device colours and assign-
ments to OSSDs and the "Safety-at-Work" monitor documentation.
Request
byte
2 7 2 6 2 5 2 4 2 3 2 2 2 1 2 0
1 7E
16
2 T O circuit
3 03
16
Response (if O
≡ 0)
byte
2
7
2
6
2
5
2
4
2
3
2
2
2
1
2
0
1 7E
16
2 T result
3 7A 6A 5A 4A 3A 2A 1A 0
… …
10 31B 30B 29B 28B 27B 26B 25B 24B
Response if O
≡ 1)
byte
2 7 2 6 2 5 2 4 2 3 2 2 2 1 2 0
1 7E
16
2 T result
3 0 1A 2A 3A 4A 5A 6A 7A
… …
10 24A 25A 26A 27A 28A 29A 30A 31A
