AS-i 3.0 Command Interface Commands of the Command Interface
Subject to reasonable modifications due to technical advances Id.-No.: 102875 Issue date - 3.12.2007 EUCHNER GmbH + Co. KG
Kohlhammerstraße 16, D-70771 Leinfelden-Echterdingen Tel. +49/711/7597-0, Fax +49/711/753316
63
With the bit "O", the sequence of the bits within the "Safety at Work" list 1 can be
chosen.
Cok Config_Ok
S0 LDS.0
AAs Auto_Address_Assign
AAv Auto_Address_Available
CA Configuration_Active
NA Normal_Operation_Active
APF APF
OR Offline_Ready
Pok Periphery_Ok
Example for O ≡ 0:
Configuration OK,
periphery OK (no peripheral fault,
2 safety slaves with released safety function,
AS-i addresses 4 and 10
Request
byte 2 7 2 6 2 5 2 4 2 3 2 2 2 1 2 0
1 7E
16
2 T O circuit
3 00
16
Response (if O ≡ 0)
byte 2 7 2 6 2 5 2 4 2 3 2 2 2 1 2 0
1 7E
16
2 T result
3 – Pok
4 OR APF NA CA AAv AAs S0 Cok
5 7 6 5 4 3 2 1 -
6 15 14 13 12 11 10 9 8
7 23 22 21 20 19 18 17 16
8 31 30 29 28 27 26 25 25
Response (if O ≡ 1)
byte
2 7 2 6 2 5 2 4 2 3 2 2 2 1 2 0
1 7E
16
2 T result
3 – Pok
4 OR APF NA CA AAv AAs S0 Cok
5 - 1 2 3 4 5 6 7
… …
8 24 25 26 27 28 29 30 31
