AS-i 3.0 Command Interface Command Interface Examples
Subject to reasonable modifications due to technical advances Id.-No.: 102875 Issue date - 3.12.2007 EUCHNER GmbH + Co. KG
Kohlhammerstraße 16, D-70771 Leinfelden-Echterdingen Tel. +49/711/7597-0, Fax +49/711/753316
76
Result: See chapter 4 "Commands of the Command Interface"
To get the input data again, the T-bit has to be reset again.
5.2 Store current configuration to the AS-i master
1. Switch master to configuration mode
2. Write the current slave configuration to the master
3. Switch master to protected mode
4. Wait until master is in normal (protected) operation mode
12-byte management
1. Switch master to config mode
Response
Byte 1 50
hex
Byte 2 80
hex
(toggle bit, master1)
Byte 3 16-bit channel 1 high byte
hex
Byte 4 16-bit channel 1 low byte
hex
Byte 5 16-bit channel 2 high byte
hex
Byte 6 16-bit channel 2 low byte
hex
Byte 7 16-bit channel 3 high byte
hex
Byte 8 16-bit channel 3 low byte
hex
Byte 9 16-bit channel 4 high byte
hex
Byte 10 16-bit channel 4 low byte
hex
Byte 11 00
hex
not used
Byte 12 00
hex
not used
PROFIBUS:
If a command of the command interface with DP V1 is being carried out, set-
ting the toggle bit is not necessary
Request: SET_OP_MODE
Byte 1 0C
hex
(SET_OP_MODE)
Byte 2 00
hex
(T = 0, master 1, single master)
Byte 3 01
hex
(= config mode)
Byte 4 00
hex
… …
Byte 12 00
hex
