AS-i 3.0 Command Interface Commands of the Command Interface
Subject to reasonable modifications due to technical advances Id.-No.: 102875 Issue date - 3.12.2007 EUCHNER GmbH + Co. KG
Kohlhammerstraße 16, D-70771 Leinfelden-Echterdingen Tel. +49/711/7597-0, Fax +49/711/753316
58
4.6.11 FP_DATA
This command is used for the data exchange with "functional profiles".
The content of the request and response bytes depends on the called function
(see chapter 4.7 Functional Profiles, page 62).
4.6.12 EXT_DIAG
With this call, the conditions when to set the ExtDiag bit can be selected.
Request
byte
2 7 2 6 2 5 2 4 2 3 2 2 2 1 2 0
1 7E
16
2 T – circuit
3 function
4 request byte 1
… …
n request byte n-3
Response
byte 2 7 2 6 2 5 2 4 2 3 2 2 2 1 2 0
1 7E
16
2 T result
3 reponse byte 1
… …
n response byte n-2
!!!
The command EXT_DIAG is valid only for the use with AS-i 3.0 PROFIBUS
Gateways
Request
byte 2 7 2 6 2 5 2 4 2 3 2 2 2 1 2 0
1 71
16
2 T – circuit
3 CF
4 APF
5 PF
6 CS
