Page 60: Write flag
AS-i 3.0 Command Interface
Commands of the Command Interface
Subject to reasonable modifications due to technical advances
Id.-No.: 102875 Issue date - 3.12.2007
EUCHNER GmbH + Co. KG
Kohlhammerstraße 16, D-70771 Leinfelden-Echterdingen
Tel. +49/711/7597-0, Fax +49/711/753316
60
4.6.14
Inverter
With this call, an AS-i slave for frequency inverters is switched from cyclical mode
to the transmission mode of four 16-bit values, in order to operate again with the
selected AS-i destination parameter.
4.6.15
Write Flag
Use this command to write the flag of a control program.
The control program of devices with control functions takes on data from the PB
interface.
Request
byte
2
7
2
6
2
5
2
4
2
3
2
2
2
1
2
0
1
7C
16
2
T
–
circuit
3
slave address
4
destination parameter
5
value 1, high byte
6
value 1, low byte
7
value 2, high byte
8
value 2, low byte
9
value 3, high byte
10
value 3, low byte
11
value 4, high byte
12
value 4, low byte
Response
byte
2
7
2
6
2
5
2
4
2
3
2
2
2
1
2
0
1
7C
16
2
T
result
Request
Byte
2
7
2
6
2
5
2
4
2
3
2
2
2
1
2
0
1
85
16
2
T
–
circuit
3
introductory address
4
number n
5
number 1
...
...
n
number n
