4.3.3.13
Command 15: "Safety Status"
With this command the status of safety monitors (external and integrated) in the
version 2 can be read.
Request buffer
Byte
2
7
2
6
2
5
2
4
2
3
2
2
2
1
2
0
1
reserved 00
16
Response buffer
Byte
2
7
2
6
2
5
2
4
2
3
2
2
2
1
2
0
1
reserved 00
16
2
OSSD 1 state
1
1. see table "Coding of status byte", page 30
3
OSSD 2 state
2
2. see table "Coding of status byte", page 30
...
...
n
OSSD n-1 state
3
3. see table "Coding of status byte", page 30
Coding of status byte
Bit [0 ... 2]
state and/or colour
0
green permanent light
1
green flashing
2
yellow permanent light
3
yellow flashing
4
red permanent light
5
red flashing
6
grey and/or off
7
reserved
Bit [6]
state and/or colour
0
no device flashes yellow in this OSSD
1
at least one device flashes yellow in this OSSD
Bit [7]
state and/or colour
0
no device flashes red in this OSSD
1
at least one device flashes red in this OSSD
