AS-i 3.0 Command Interface Commands of the Command Interface
Subject to reasonable modifications due to technical advances Id.-No.: 102875 Issue date - 3.12.2007 EUCHNER GmbH + Co. KG
Kohlhammerstraße 16, D-70771 Leinfelden-Echterdingen Tel. +49/711/7597-0, Fax +49/711/753316
20
n is the length of the sub-string that is to be written to the buffer starting from index
(i). When i = 0, the transfer is started.
Request
Byte 2 7 2 6 2 5 2 4 2 3 2 2 2 1 2 0
1 4E
16
2 T circuit
3 slave address
4 buffer index (i) high
5 buffer index (i) low
6 command 1
1. For a list of all supported commands
20>.
7 number of (n)
8 data 0
… ...
n+7 data n-1
Espoused commands
see page Command Description
page 23 1 read string S-7.4 ID
page 23 2 read string S-7.4 diag
page 23 3 read string S-7.4 param string
page 23 4 write S-7.4 param string
page 24 5 transfer S-7.5
page 24 6 read S-7.5 cyclic 16-bit slave configuration
page 24 7 read safety monitor sorted by OSSD
page 26 8 read safety monitor unsorted (all devices) by OSSD
page 26 9 reserved / not defined
!!! page 27 10 safety monitor diagnosis
!!! page 27 11 shutdown-history, separate for each release circuit
!!! page 27
12 safety monitor diagnosis, but the module allocation has been con-
sidered
!!! page 27
13 safety monitor diagnosis, but the module allocation has been con-
sidered
!!! page 28 14 diagnosis / shutdown-history, separate for each release circuit
!!! page 30 15 safety status
!!!
The commands 10 ... 15 are available only with safety monitors (external and
integrated) in the version 2 and higher.
