AS-i 3.0 Command Interface Commands of the Command Interface
Subject to reasonable modifications due to technical advances Id.-No.: 102875 Issue date - 3.12.2007 EUCHNER GmbH + Co. KG
Kohlhammerstraße 16, D-70771 Leinfelden-Echterdingen Tel. +49/711/7597-0, Fax +49/711/753316
71
4.7.6 Integrated AS-i sensors: Availability
(Function: 04
16
)
List of the integrated slaves according to profile S-1.1 whose input data bits D2
("Availability") are deleted.
For creating this list, CDI and IDI are used only. Integrated AS-i slaves which are
projected but not existing therefore are not entered here.
Request
byte 2 7 2 6 2 5 2 4 2 3 2 2 2 1 2 0
1 7E
16
2 T O circuit
3 04
16
Response (if O ≡ 0)
byte 2 7 2 6 2 5 2 4 2 3 2 2 2 1 2 0
1 7E
16
2 T result
3 7 6 5 4 3 2 1 0
… …
6 31 30 29 28 27 26 25 24
Response (if O
≡ 1)
byte 2 7 2 6 2 5 2 4 2 3 2 2 2 1 2 0
1 7E
16
2 T result
3 0 1 2 3 4 5 6 7
… …
6 24 25 26 27 28 29 30 31
