AS-i 3.0 Command Interface
Commands of the Command Interface
Subject to reasonable modifications due to technical advances
Id.-No.: 102875 Issue date - 3.12.2007
EUCHNER GmbH + Co. KG
Kohlhammerstraße 16, D-70771 Leinfelden-Echterdingen
Tel. +49/711/7597-0, Fax +49/711/753316
15
4.1.7
Read 4 7.3 Slave out. Data (RD_7X_OUT_X)
With this command, the four 16-bit channels of four AS-i output slaves with suc-
cessive addresses according to slave profile (S-7.3, S-7.4, S-7.5, S-7.A.8, S.A.9,
S-7.A.A) can be read.
4.1.8
Read 16 channels 16-bit Slave in. Data (OP_RD_16BIT_IN_CX)
With this command, the 16 channels of the 16-bit input-data for slaves with suc-
cessive addresses according to slave profile (S-7.3, S-7.4, S-7.5, S-7.A.8, S.A.9,
S-7.A.A) can be read.
Request
byte
2
7
2
6
2
5
2
4
2
3
2
2
2
1
2
0
1
55
16
2
T
–
circuit
3
–
0
1st slave address
Response
byte
2
7
2
6
2
5
2
4
2
3
2
2
2
1
2
0
1
55
16
2
T
result
3
1st slave, channel 1, high byte
…
…
34
4th slave, channel 4, low byte
Request
Byte
2
7
2
6
2
5
2
4
2
3
2
2
2
1
2
0
1
4C
16
2
T
–
circuit
3
1. slave
4
1. channel
Response
Byte
2
7
2
6
2
5
2
4
2
3
2
2
2
1
2
0
1
4C
16
2
T
result
3
1. slave, channel 1, high byte
4
1. slave, channel 1, low byte
…
…
33
16. channel, high byte
34
16. channel, low byte
