AS-i 3.0 Command Interface Commands of the Command Interface
Subject to reasonable modifications due to technical advances Id.-No.: 102875 Issue date - 3.12.2007 EUCHNER GmbH + Co. KG
Kohlhammerstraße 16, D-70771 Leinfelden-Echterdingen Tel. +49/711/7597-0, Fax +49/711/753316
31
4.4 AS-i Diagnosis
4.4.1 Overview of the commands
4.4.2 Get Lists and Flags (Get_LPS, Get_LAS, Get_LDS, Get_Flags)
(GET_LISTS)
With this call, the following entries of the AS-i Master can be read:
• The list of active AS-i slaves (LAS)
• The list of detected AS-i slaves (LDS)
• The list of projected AS-i slaves (LPS)
• The flags according to the AS-i slave specification
Values for command
see page Command Value Meaning
Req
Len Res
Len
page 31 GET_LISTS 30
16
Get LDS, LAS, LPS, Flags 2 29
page 33 GET_FLAGS 47
16 Get_Flags 2 5
page 34 GET_DELTA 57
16 Get list of config. diff. 2 10
page 35 GET_LCS 60
16
Get LCS 2 10
page 35 GET_LAS 45
16 Get_LAS 2 10
page 36 GET_LDS 46
16 Get_LDS 2 10
page 37 GET_LPF 3E
16
Get_LPF 2 10
page 37 GET_LOS 61
16 GET_LOS 2 10
page 38 SET_LOS 62
16 SET_LOS 10 2
page 39 GET_TECA 63
16 Get transm.err.counters 2 34
page 40 GET_TECB 64
16
Get transm.err.counters 2 34
page 41 GET_TEC_X 66
16 Get transm.err.counters 4 ≥3
page 41 READ_FAULT_DETECTOR 1
1. The command READ_FAULT_DETECTOR is valid only for the use with masters which support this function. Please see the user manual of the
master for further information.
10
16 Read Fault Detector 2 4
page 42 READ_DUPLICATE_ADDR 2
2. The command READ_DUPLICATE_ADDR is valid only for the use with masters which support this function. Please see the user manual of the
master for further information.
11
16 Read List of Duplicate Addresses 2 10
Request
byte 2 7 2 6 2 5 2 4 2 3 2 2 2 1 2 0
1 30
16
2 T O circuit
Response (if O
≡ 0)
byte
2
7
2
6
2
5
2
4
2
3
2
2
2
1
2
0
1 30
16
2 T result
3 7A 6A 5A 4A 3A 2A 1A 0A
