Setting the toggle bit:
The permanent parameter for the 16 bit module is written.
This command must be repeated for all 31 A-slaves and all 31 B-slaves. If you
don't connect a slave to an address, write the default value to the master (F
hex
) as
a permanent parameter.
5. Switch Master to Protected Mode
No result because toggle bit = 0.
Request: SET_PP
Byte 1 43
hex
(SET_PP)
Byte 2 80
hex
(T = 0, master 1, single master)
Byte 3 04
hex
(slave address to write to master)
Byte 4 07
hex
(PP to write (use low nibble)
Byte 5 00
hex
… …
Byte 12 00
hex
Response
Byte 1 43
hex
Byte 2 80
hex
(T = 1, Result = 0)
Byte 3 00
hex
… …
Byte 12 00
hex
Request: SET_OP_MODE
Byte 1 0C
hex
(SET_OP_MODE)
Byte 2 00
hex
(T = 0, master 1, single master)
Byte 3 00
hex
(= protected mode)
Byte 4 00
hex
… …
Byte 12 00
hex
Response
Byte 1 00
hex
(or old values)
Byte 2 00
hex
(or old values)
… …
Byte 12 00
hex
(or old values)
