AS-i 3.0 Command Interface Commands of the Command Interface
Subject to reasonable modifications due to technical advances Id.-No.: 102875 Issue date - 3.12.2007 EUCHNER GmbH + Co. KG
Kohlhammerstraße 16, D-70771 Leinfelden-Echterdingen Tel. +49/711/7597-0, Fax +49/711/753316
35
4.4.5 Get list of corrupted Slaves (GET_LCS and GET_LCS_R6 (6CH))
The call GET_LCS_R6 (6CH) differs to the call GET_LCS in the half long LCS list.
With the bit 2 5 is selected if the upper (=1) or lower (=0) part of the LCS is read.
Read first with 2 5 in order to create a local copy of the LCS. Reading with bit 2 5 =1
transmits the upper part of the copy.
With the call GET_LCS, the List of Corrupted Slaves (LCS) can be read.
4.4.6 Get list of activated Slaves (GET_LAS)
With this call, the list of activated slaves (LAS) can be read.
Request
byte
2
7
2
6
2
5
2
4
2
3
2
2
2
1
2
0
1 60
16
2 T O circuit
Response (if O ≡ 0)
byte 2 7 2 6 2 5 2 4 2 3 2 2 2 1 2 0
1 60
16
2 T result
3 7A 6A 5A 4A 3A 2A 1A 0A
… …
10 31B 30B 29B 28B 27B 26B 25B 24B
Response (if O ≡ 1)
byte 2 7 2 6 2 5 2 4 2 3 2 2 2 1 2 0
1 60
16
2 T result
3 0A 1A 2A 3A 4A 5A 6A 7A
… …
10 24B 25B 26B 27B 28B 29B 30B 31B
Request
byte
2
7
2
6
2
5
2
4
2
3
2
2
2
1
2
0
1 45
16
2 T O circuit
