AS-i 3.0 Command Interface Commands of the Command Interface
Subject to reasonable modifications due to technical advances Id.-No.: 102875 Issue date - 3.12.2007 EUCHNER GmbH + Co. KG
Kohlhammerstraße 16, D-70771 Leinfelden-Echterdingen Tel. +49/711/7597-0, Fax +49/711/753316
37
4.4.8 Get list of peripheral faults (GET_LPF)
With this call, the list of peripheral faults (LPF) signaled by the AS-i slaves is read
out from the AS-i master. The LPF is updated cyclically by the AS-i master. If and
when an AS-i slave signals faults of the attached peripherals (for example broken
wire) can be found in the description of the AS-i slave.
4.4.9 Get list of offline Slaves (GET_LOS)
With this call, the list of slaves causing the offline phase when a configuration error
occurs in being read out (List of Offline Slaves, LOS).
The user can choose the reaction of the master when a configuration error occurs.
The master can be switched off line when an important slave causes a configura-
tion error; less important slaves can send an error to the host, AS-i however will
not be switched offline.
Request
byte 2 7 2 6 2 5 2 4 2 3 2 2 2 1 2 0
1 3E
16
2 T O circuit
Response (if O
≡ 0)
byte 2 7 2 6 2 5 2 4 2 3 2 2 2 1 2 0
1 3E
16
2 T result
3 7A 6A 5A 4A 3A 2A 1A 0A
… …
10 31B 30B 29B 28B 27B 26B 25B 24B
Response (if O
≡ 1)
byte 2 7 2 6 2 5 2 4 2 3 2 2 2 1 2 0
1 3E
16
2 T result
3 0A 1A 2A 3A 4A 5A 6A 7A
… …
10 24B 25B 26B 27B 28B 29B 30B 31B
Request
byte 2 7 2 6 2 5 2 4 2 3 2 2 2 1 2 0
1 61
16
2 T O circuit
