Parameter

Modbus

Parameter No.

ASCII Ident &

Message Types

Notes

Product Revision
Level

129

RO

Bits 0 – 7: Alpha part of PRL. (e.g. A =
01hex)

Bits 8 – 15: Numeric part of PRL. (e.g.
13 = 0Dhex)

Firmware Version

130

RO

Bits 0 – 4: Revision number (1,2...)
Bits 5 – 9: Alpha version (A=0, B=1...)

Bits 10 – 15: Numeric version (starting
from 121 = 0)

Input status

133

RO

Input status. Read Only.
Bit 0: Sensor break flag
Bit 1: Under-range flag
Bit 2: Over-range flag

Remote Setpoint
Lower Limit

2123

R/W

Y

Type 2, 3/4

R/W

RSP value to be used when RSP
input is at minimum. -1999 to 9999

Remote Setpoint
Upper Limit

2124

R/W

X

Type 2, 3/4

R/W

RSP value to be used when RSP
input is at minimum. -1999 to 9999

Option Slot 1
Re-transmit output
Maximum

2214

R/W

Maximum scale value for retransmit
output in slot 1, -1999 to 9999.

Option Slot 1
Re-transmit output
Minimum

2215

R/W

Minimum scale value for retransmit
output in slot 1, -1999 to 9999.

Option Slot 2
Re-transmit output
Maximum

2224

R/W

Maximum scale value for retransmit
output in slot 2, -1999 to 9999.

Option Slot 2
Re-transmit output
Minimum

2225

R/W

Minimum scale value for retransmit
output in slot 2, -1999 to 9999.

Option Slot 3
Re-transmit output
Maximum

2234

R/W

Maximum scale value for retransmit
output in slot 3, -1999 to 9999.

Option Slot 3
Re-transmit output
Minimum

2235

R/W

Minimum scale value for retransmit
output in slot 3, -1999 to 9999.

Note:
Some of the parameters that do not apply for a particular configuration will accept reads and
writes (e.g. attempting to scale a Linear output which has not been fitted). Read only parameters
will return an exception if an attempt is made to write values to them.
