Despatch P1400+ Temperature Controller - Manual (Page 43)

37
Parameter Lower
Display Upper
Display Description Default
Value
When
Visible
0_10 0 to 10 V DC output
2_10 2 to 10 V DC output
0_20 0 to 20 mA DC output
1 Range
4_20 4 to 20 mA DC output
Lin
Retransmit
Output 1 Scale
maximum ro1H
−1999 −1999 −1999 −1999
to
9999 9999 9999 9999
Display value at which output will be
maximum
Range
max Use1 =
retS
or
retP
Retransmit
Output 1 Scale
minimum ro1L −1999 −1999 −1999 −1999
to
9999 9999 9999 9999
Display value at which output will be
minimum
Range min Use1 =
retS or
retP
Output 2
Usage USE2 As for output 1 Sec if dual
control
selected
else
A2_d
Opn2
is not
none
Linear Output
2 Range tYP2 As for output 1 0_10 0_10 0_10 0_10 Opn2 =
Lin
Retransmit
Output 2 Scale
maximum ro2H
−1999 −1999 −1999 −1999
to
9999 9999 9999 9999
Display value at which output will be
maximum
Range
max Use2 =
retS or
retP
Retransmit
Output 2 Scale
minimum ro2L −1999 −1999 −1999 −1999
to
9999 9999 9999 9999
Display value at which output will be
minimum
Range min Use2 =
retS or
retP
Output 3
Usage USE3 As for output 1 Al_d Opn3
is not
none
Linear Output
3 Range tYP3 As for output 1 0_10 0_10 0_10 0_10 Opn3 =
Lin
Retransmit
Output 3 Scale
maximum ro3H
−1999 −1999 −1999 −1999
to
9999 9999 9999 9999
Display value at which output will be
maximum
Range
max Use3 =
retS or
retP
Retransmit
Output 3 Scale
minimum ro3L −1999 −1999 −1999 −1999
to
9999 9999 9999 9999
Display value at which output will be
minimum
Range min Use3 =
retS or
retP
Display
Strategy disp
1111
,
2 2 2 2
,
3 3 3 3
,
4 4 4 4
,
5 5 5 5
or 
6666
(see Operator Mode)
1111 Always
ASCI ASCII
Mbn Modbus with no parity
MbE Modbus with Even Parity
Comms
Protocol Prot
Mbo Modbus with Odd Parity
Mbn OpnA = r
485
