SECTION 8: 1400+ CONTROLLER – MODEL GROUP
These controllers combine technical functionality, field flexibility and ease of use to give you the best
in comprehensive process control.
Heat/Cool operation
Loop alarm
Auto/Manual Tuning
Remote or Dual setpoint selection options
Two process alarms
RS485 Modbus and ASCII comms option
Ramping setpoint
PC configuration option
8.1 1400+ Controllers - Configuration Mode
This mode is normally used only when the instrument is configured for the first time or when a major
change is made to the instruments characteristics. The Configuration Mode parameters must be set
as required before adjusting parameters in Setup Mode, or attempting to use the instrument in an
application.
Entry into the Configuration Mode
CAUTION:
Adjustments to these parameters should only be performed by personnel competent and
authorised to do so.
Configuration is entered from
Select Mode
Hold down and press to force the controller into the Select Mode.
then
Press or to navigate to the Configuration Mode option, then press .
Note:
Entry into this mode is security-protected by the Configuration Mode Lock Code. Refer to the
Unlock Code section for more details.
Scrolling through Parameters and Values
Press to scroll through the parameters (parameters are described below).
Note:
Only parameters that are applicable to the hardware options chosen will be displayed.
