100
14.8 Reference Conditions
Ambient Temperature: 20
°
C ±2
°
C.
Relative Humidity: 60 to 70%.
Supply Voltage: 100 to 240V AC 50Hz ±1%.
Source Resistance: <10 Ω for thermocouple input.
Lead Resistance: <0.1 Ω /lead balanced (Pt100).
14.9 Operating Conditions
Ambient Temperature (operating): 0
°
C to 55
°
C.
Ambient Temperature (storage): -20
°
C to 80
°
C.
Relative Humidity: 20% to 95% non-condensing.
Altitude: Up to 2000m above sea level.
Supply Voltage: Either 100 to 240V ±10% AC 50/60Hz
or 20 to 48V AC 50/60Hz & 22 to 55V DC
Power Consumption: 5W / 7.5 VA maximum.
Source Resistance: 1000 Ω maximum (thermocouple).
PT100 Input Lead Resistance: 50 Ω per lead maximum, balanced
14.10 Standards
Conformance Norms: CE, UL, ULC.
EMC standards: EN61326*
Safety Standards: EN61010 and UL3121.
Pollution Degree 2, Installation Category II.
Also FM 3545, 1998 for Limit Controllers.
Front Panel Sealing: IP66
Note:
*For disturbances induced by RF fields of 10V/m 80% AM at 1kHz the input accuracy
specification is changed to 0.25% in the frequency bands 465 to 575 MHz and 630 to 660
MHz.
14.11 Physical Specifications
Dimensions: Depth behind
panel: 110mm ( 1 /
16
DIN instruments).
100mm ( 1 /
8
& 1 /
4
DIN instruments).
Front bezel
size (w x h): 48 x 48mm (
1
/
16
DIN instruments).
48 x 96mm ( 1 /
8
DIN controllers).
96 x 48mm ( 1 /
8
DIN indicators).
96 x 96mm ( 1 /
4
DIN instruments).
Mounting: Plug-in with panel mounting fixing strap.
Panel cut-out size (w x h):: 45mm x 45mm (
1
/
16
DIN instruments).
45 x 92mm ( 1 /
8
DIN controllers).
92 x 45mm ( 1 /
8
DIN indicators).
92mm x 92mm ( 1 /
4
DIN instruments).
Terminals: Screw type (combination head).
Weight: 0.21kg maximum.
