Option Slot 1 - SSR Driver Output Module

If option slot 1 is fitted with an

SSR

driver output module, make connections as illustrated. The solid-

state relay driver is a 0-10V DC signal, load impedance must be no less than 500 ohms. SSR driver
outputs are not isolated from the signal input or other SSR driver outputs.

Figure 16. Option Slot 1 - SSR Driver Module Connections

Option Slot 1 - Triac Output Module

If option slot 1 is fitted with a Triac output module, make connections as shown. This output is rated
at 0.01 to 1 amp @ 280V AC 50/60Hz. (140V max for direct Valve Motor control).

Figure 17. Option Slot 1 - Triac Module Connections

Option Slot 1 - Linear Voltage or mADC Output module

If option slot 1 is fitted with a DC linear output module, make connections as illustrated.

Figure 18. Option Slot 1 - Linear Voltage & mADC Module Connections

19

20

_

21

+

19

20

_

21

+

20

21
