Despatch P1400+ Temperature Controller User Manual

Page 49

8.3 1400+ Controllers - Operator Mode

This is the mode used during normal operation of the instrument. It can be accessed from Select
Mode, and is the usual mode entered at power-up. The available displays are dependent upon
whether Dual or Remote Setpoint modes are being used, whether Setpoint Ramping is enabled and
the setting of the Display Strategy parameter in Configuration Mode.

WARNING:

IN NORMAL OPERATION, THE OPERATOR MUST NOT REMOVE THE CONTROLLER FROM ITS
HOUSING OR HAVE UNRESTRICTED ACCESS TO THE REAR TERMINALS, AS THIS WOULD
PROVIDE POTENTIAL CONTACT WITH HAZARDOUS LIVE PARTS.

CAUTION:

Set all Configuration Mode parameters and Set Up Mode parameters as required before
starting normal operations.

1400+ Controllers – Extended Operator Mode

Using the PC configuration software, it is possible to extend the Operator Mode displays available by
adding parameters from Setup Mode. When an extended Operator Mode is configured the additional
parameters are available after the standard operator displays.

Navigating in Operator Mode

Press to move between displays.

When a display value can be adjusted, use or to change its value.

Note:
The operator can freely view the parameters in this mode, but alteration depends on the settings
in the Configuration and Set Up Modes. All parameters in Display strategy 6 are read only, and
can only be adjusted via Setup mode.
