4) Press the MENU key multiple times to tab right and the ESC key
multiple times to tab left until the MATL menu is highlighted and
displaying the submenu items.
5) Use the UP and DOWN arrow keys to scroll through the sub menu
items until TYPE is highlighted.
6) Press the ENTER key to display the list of bolt types.
7) Press the UP and DOWN arrow keys to scroll through the bolt material
types until the appropriate bolt type is highlighted.
8) Press the ENTER key to display the confirmation screen.
9) Press the OK key to select the bolt type and return to the menu screen,
or press ESC to cancel the bolt type selection.
10) The new bolt type selected will be displayed to the right of the sub
menu item. Write down the values for the Velocity and Temperature
Coefficient also displayed next to the sub menu items below. These
values will be needed in one of the following steps.
11) Press the MENU key multiple times to tab right and the ESC key
multiple times to tab left until the GEOM menu is highlighted and
displaying the submenu items.
