Dakota Ultrasonics MINI--MAX User Manual
Page 134
Dakota Ultrasonics
128
Adjusting the Width using the Hot Menus
1) Press the MEAS key once to activate measure menu items. Press the
MEAS key multiple times to move right and the ESC key multiple times
to move left, until the WIDTH cell is highlighted.
2) Press the UP, DOWN, LEFT, and RIGHT arrow keys to scroll the
highlighted value.
3) Alternatively, press the ENTER key to display the Digits Edit Box.
4) Press the UP and DOWN arrow keys to scroll the highlighted value.
5) Press the LEFT and RIGHT arrow keys to scroll the digit locations.
6) Repeat steps 4 & 5 until the WIDTH value is correctly displayed.
7)
Press the OK key to return to the measurement screen, or ESC to
cancel entering the WIDTH.
The user can also access and adjust the width from the tabbed menus.
However, this method is a more tedious than making the adjustments using the
Hot Menus. The procedure using the tabbed menus is outlined below:
