10. Layout menu
10. LAYOUT MENU
Overview
• Overview flow
• Main window
• PIP window
• Layout file services
10.1 Overview flow
Overview
Level 1 Level 2 Level 3 Level 4
Layout
Main window
Source
Size
Position
PIP window
PIP window [ON/OFF]
Source
Size
Position
Layout file services
Load
Main full screen
PIP top right
Split top bottom
Rename
Delete
Copy / Save as
Zoom/Focus Same for each layout yes
no
10.2 Main window
Overview
• Source selection
• Size adjustment
• Position adjustment
When active layout is read only
When the active layout is a read only layout, the projector will ask to create a new layout.
Use the ▲ or ▼ key to select Yes or No and press ENTER.
If Yes is selected an Enter layout name window opens.
