12. Alignment menu
12. ALIGNMENT MENU
About this chapter
This chapter describes the alignment of the projector once the physical installation is finished. Via the software, the image will be
perfectly aligned on the screen.
Overview
• Overview flow
• Orientation
• Lens adjustment
• Side keystone
• Blanking
• Intensity
• Gamma
• Internal pattern
• Color space
• White peaking
• ScenergiX
12.1 Overview flow
Overview
Level 1 Level 2 Level 3
Alignment
Orientation
Front Table
Front Ceiling
Rear Table
Rear Ceiling
Lens
Zoom/Focus
Shift
Side keystone
Blanking
Top
Bottom
Left
Right
Reset
Intensity
Gamma
Internal patterns
Checker board
Color bars
Convergence
Focus
Full screen black
Full screen blue
R59770057 CLM HD8 15/03/2010 115
