5. Connections

Pin

Description

2

Cold

3

Hot

4

Return - (or not used)

5

Return + (or not used)

DMX

DMX-512 Lighting protocol over RS-485 interface. Carries information of 512 channels from a lighting controller to
lighting devices. Standardized by USITT.

42

R59770057 CLM HD8 15/03/2010
