Physical installation – Barco CLM HD8 R9050130 User Manual
Page 31
3. Physical installation
Image 3-16
Mounting rigging clamps
6. Place all four rigging clamps in open position as illustrated.
Image 3-17
Opening clamps
7. Place the projector (upside down) under the truss installation and lower the truss until the support bars of the truss are nearby
the rigging clamps on the projector.
R59770057 CLM HD8 15/03/2010
27
