D. Specifications
D. SPECIFICATIONS
Overview
•
•
Specifications CLM 5 cable input (multi purpose)
•
Specifications CLM HDSDI – SDI input
•
•
Specifications CLM DVI HDCP input
D.1 Specifications CLM HD8
Overview
Ambient temperature
Max. 40°C (104°F)
Brightness uniformity
95%
Communication
•
1x RS-232C/RS-422 IN (D-9 connector)
•
1x RS-232C/RS-422 OUT (D-9 connector)
•
1x RS-232C IN (XLR connector)
Compatibility
•
All current video sources (PAL, SECAM, NTSC) in Composite, S-VHS, Component
or RGB formats
•
All currently proposed HDTV, extended and improved television standards (1080i,
720p)
•
All computer graphics formats from VGA, SVGA, XGA, SXGA,full HD to UXGA
•
Most Macintosh computers
•
Electronic workstations with a resolution up to 1600 x 1200 pixels at 75 Hz
•
Most computer sources with a pixel clock up to 200 MHz
•
DVI sources up to SXGA+
Contrast ratio
1200:1 (full field)
High contrast mode:
Contrast enhancement by optical dowser
Dimensions
W x L x H
692 x 442 x 293 mm
27.24 x 17.40 x 11.54 inch
(excl. carrying handle + rigging points)
Display
1 Chip DLP HD (resolution 1920*1080(aspect 16/9))
Dust filters
High density filters
Electromagnetic Interference
Complies with FCC rules & regulations, part 15 Class A and CE EN55022 Class A
Features
•
DMX512 control of optical dimming, electronic dimming, zoom, focus, lens shift,
input select
•
Advanced picture-in-picture
•
Seamless switching with effects
•
Carry handle/frame
•
Rigging points (touring kit)
•
Flexible positioning (portrait/ landscape/any setup possible)
•
Brilliant Color processing
Heat dissipation
BTU 5500
Input source compatibility
max. input resolution up to UXGA (1,600 x 1,200) and HD (1,920 x 1,080)
R59770057 CLM HD8 15/03/2010
