The output mode for this display is 2-2/3 mode, and can be seen in Figures 5 , 6 , and 7 , which yields the connections
shown in Table 18 (level buffering may be required to meet the electrical characteristics).
EP93xx Pin
Name
Corresponding Entry in Table “Output
Pixel Transfer Modes” in the EP93xx
User’s Guide Raster Chapter
KCS057QV1AJ-G20 Pin
Name (Level shifting may
be required)
LB064V02-B1 Pin
Number
SPCLK X CP 3
VCSYNC X FRM 1
HSYNC X LOAD 2
P[0] B0[7] / R2[7] / G5[7] D7 8
P[1] G0[7] / B3[7] / R5[7] D6 9
P[2] R0[7] / G3[7] / B6[7] D5 10
P[3] B1[7] / R3[7] / G6[7] D4 11
P[4] G1[7] / B4[7] / R6[7] D3 12
P[5] R1[7] / G4[7] / B7[7] D2 13
P[6] B2[7] / R4[7] / G7[7] D1 14
P[7] G2[7] / B5[7] / R7[7] D0 15
Table 18. Connections to a Kyocera KCS057QV1AJ-G20
