- 151 -
20.1.4. Cooperation with E2R
E2R is a control system, it controls all weighments realised on a
measuring device. Upon activation of this option operations on some
Databases are only possible with the use of a computer (options are
not accessible on a measuring device). In ordert o start cooperation
with E2R system set value of parameter.
Caution:
< E2R System> parameter may be updated by the device manufacturer or
authorized persons.
20.2 Printer
In the submenu the balance’s user has a possibility of choosing a port
and device, to which the data is sent by pressing button on balance. The
content of the data being transferred is set in parameter
GLP>.
Procedure:
− press button
− enter the menu
− and then enter in menu group
− set the balance parameters related to the cooperation with the
printer
to which the printer is to be connected
Accessible options:
COM 1
or COM 2 – RS 232 port, to which the printer is connected
USB
type A – USB port, to which PCL printer or EPSON printer is
connected
WIFI
–WIFI port, which can send data to special software
manufactured by RADWAG e.g. WIN measurement, opened on the
computer connected to the balance via WIFI.
USB flash drive
–USB port type A, to which external memory flash
drive is connected
USB PC
–USB port type B, to which the computer with the special
software by RADWAG is connected e.g. WIN measurement
Example of the measurement printout is described in the PRINT-OUTS section.
Additionaly the user can send a controlling code (of a hexadecimal form) to a
printer either at the beginning of the printout - or at the end of it -
