Technical Specifications
59
59
Go to the Menu and restore your specific settings. Prepare and store all
necessary setups.
13 Technical Specifications
Table 9 includes the technical specifications:
Table 9: Technical Specifications of the VS-162V Video Matrix Switcher
INPUTS: 16 composite video, or 8 s-Video, or 4 RGBS, or 5 YUV, 1 Vpp / 75
Ω on BNC
connectors
OUTPUTS: 16 composite video, or 8 s-Video, or 4 RGBS, or 5 YUV, 1 Vpp / 75
Ω on BNC
connectors
VIDEO BANDWIDTH: 90 MHz (-3dB)
VIDEO CROSSTALK: <-52 dB @5MHz
NON-LINEARITY <0.01%
VIDEO S/N: 70.2 dB
DIFF. GAIN: <0.01 %
DIFF. PHASE: <0.01 Deg
K-FACTOR: <0.05%
CONTROL: 38 selector switches; RS-232, RS-485, IR remote, dry keyboard extension
SWITCHING: Vertical interval
POWER SOURCE: 230V AC, 50/60 Hz, (115VAC, U.S.A.) 10VA
DIMENSIONS: 19” x 7” x 2U W, D, H, rack mountable
WEIGHT: 3.5kg (7.8lbs) approx.
ACCESSORIES: Power cord, null-modem adapter, Windows®-based Kramer control software.
OPTIONS: External IR receiver cable
14 Communication Protocol
Table 10 includes the Protocol 2000
1
hexadecimal codes
2
1 Full details are available on our Web site: www.kramerelectronics.com
. The
communication parameters are: 9600 baud, with no parity, 8 data bits and 1
stop bit.
2 This example assumes MACHINE # 1, and node 0
