Page 48

KRAMER: SIMPLE CREATIVE TECHNOLOGY

MENU Commands

2. Press the TAKE button.

The displays show the messages:

Use OUTkey to configure

1: CV 2: YC 3: YUV 4: RGBS

current: 1: CV

3. Press the appropriate

OUT button # 2, 3 or 4

Press TAKE to configure

for x

The MATRIX display shows the message:

Where x is the new VIDEO FORMAT setting, either Y/C, YUV or RGBS

(At this stage, you can still configure a different video format by pressing

another OUT button). To exit the VIDEO FORMAT setting command,
press a non-relevant button, such as an IN button.

4. Press the TAKE button again.

The displays show the messages:

FORMAT changed!

All INs/OUTs reset

current: 1: x

Where x is the new VIDEO FORMAT setting, either Y/C, YUV or RGBS

11.4 Setting the MACHINE ADDRESS

Press the MENU button until you reach the Setting the MACHINE
ADDRESS command. Choose the standalone or the large matrix setting.
You set the MACHINE ADDRESS using the OUTkeys # 1 to 9, and 10 (for
0). The OUTkeys function on a decimal-basis, and not on a positional-basis.
For example, to enter the # 15, press # 1 followed by # 5 (not # 15).

You can change the MACHINE ADDRESS from:
• The standalone setting to a large matrix setting (see section

11.4.1

)

• A large matrix setting to the standalone setting (see section

11.4.2

)

• A large matrix setting to a large matrix setting with a different

MACHINE ADDRESS (see section

11.4.3

)

1 If currently configured for composite (CV)

2 Depending on the required video format
