Operating Your Video Matrix Switcher
35
35
10.5 Clearing
1
You can clear (delete):
• One output (see section
10.5.1 )
• Several outputs (see section
10.5.2 )
• All outputs (see section
10.5.3 )
10.5.1 Clearing an Output
To clear an output (in the AT ONCE mode):
1. Press the appropriate OUT button.
The MATRIX display shows the two flashing digits, representing the
present input number for that specific output
2
out # x
. If the present input is clear,
the two flashing digits 00 appear in the MATRIX display.
The STATUS Display shows the message:
Where x is the output number
2. Press the OFF button
3
out # x
reset
.
The input is cleared and the MATRIX display does not show any Input # in
its place.
The STATUS Display momentarily shows the message:
Where x is the output number
To clear an output (in the CONFIRM mode (the TAKE LED is lit)):
1. Repeat step 1 above.
2. Press the OFF button
3
.
The MATRIX display shows the two flashing digits 00 instead of the
previous two flashing digits and the TAKE LED flashes.
The STATUS Display shows
4
out # x
reset
the message:
Where x is the output number
1 “Clearing” means disconnecting the output from any of the inputs, and leaving it disconnected
2 For example, pressing OUT button 9 shows the flashing digits 01 if input 1 was previously routed to OUT 9
3 You can press the OFF button first, and then an OUT button (the order is irrelevant)
4 Continuously, within the limit of the timeout (approximately 30 seconds to one minute)
