MENU Commands
50
11.5.2 Configuring a SWITCHING METHOD
To choose a SWITCHING METHOD setting, do the following:
1. Press the MENU button until you reach the SWITCHING METHOD
setting.
The MATRIX display shows the message:
SWITCHING METHOD setting
yes -> TAKE, next -> MENU
2. Press the TAKE button.
The displays show the messages:
Use OUTkey to configure
1: noVIS 2: EXT 3: INT#1 4:MTX
Current
External
1
3. Press an OUT button from 1, 2, 3 or 4. For example, OUT button # 3 to set
the internal sync configuration.
The TAKE LED flashes and the MATRIX display shows the message:
Press TAKE to configure
from INTERNAL (Input #1)
4. Press the TAKE button.
The displays show the messages:
SWITCHING METHOD
changed
current:
From In #1
11.6 Choosing the Extended Keyboard Setting
Section 9.4 describes how to connect a remote unit. Activate or deactivate it
by setting the extended Keyboard setting ON or OFF.
To set the extended KEYBOARD mode, do the following:
1. Press the MENU button until reaching the extended Keyboard setting.
The MATRIX display shows the message:
extended KEYBOARD setting
yes -> TAKE, next -> MENU
2. Press the TAKE button.
The displays show the messages:
Outkey 1: External keys OFF
2: External keys ON
current:
X-key ON
2
1 Indicating that the machine is currently set to the external switching method setting
2 Indicating that the external keys are currently activated
