MENU Commands
48
7. Press the TAKE button again.
The displays show the messages:
MACHINE ADDRESS
changed
current #
x
After a few seconds, The displays show the messages:
SET highest MACHINE ADDRESS
use OUTkey 1-9, 0
current #
x
8. Press an OUT button # 1-9, 0.
The STATUS Display shows the message:
current:
x
Where x is the OUT button # pressed
9. Press the TAKE button again.
The MATRIX display shows the message:
Change highest MACH. ADDR. ?
Press TAKE to confirm
10. Press the TAKE button again.
The MATRIX display shows the message:
HIGHEST MACHINE ADDRESS
Changed
11.5 Choosing the SWITCHING METHOD Setting
Section 11.5.1 describes the SWITCHING METHOD settings for
standalone units and large matrices. Section 11.5.2 describes how to
configure a SWITCHING METHOD.
11.5.1 Understanding the SWITCHING METHOD Settings
Setting the VS-162V unit as a Stand-Alone UNIT
1
• NoVIS - switching occurs immediately after completion of front
panel or dry-contact operation or immediately after receiving an
RS-232 or RS-485 command, or an IR command. The switching
is independent of the vertical reference
provides a choice of
three SWITCHING METHOD settings:
• EXT (external sync) - switching occurs during the vertical
interval of the video reference signal connected to the IN SYNC
2
1 Via the MACHINE ADDRESS setting (as section 11.4 describes)
2 Item 1 in Figure 1
