Connecting a Control Interface

24

You can connect any of the following:
• Two VS-162V units, using a null-modem adapter (see section

9.1.1

) or without using a null-modem adapter (see section

9.1.2

)

• The 9-pin D-sub COM port of a PC to a VS-162V unit with a

null-modem adapter (see section

9.1.3

) or without a null-modem

adapter (see section

9.1.4

)

• The 25-pin D-sub COM port of a PC to a VS-162V unit with a

null-modem adapter (see section

9.1.5

) or without a null-modem

adapter (see section

9.1.6

)

9.1.1 Connecting Two Units with a Null-Modem Adapter

To connect two VS-162V units, using a null-modem adapter provided
with the machine (default):

1. Connect a flat cable

1

2. On the second VS-162V unit, set DIP 7 OFF (enabling null-modem

adapter use).

between the RS-232 OUT 9-pin D-sub port on the first

VS-162V unit and the null-modem adapter that attaches to the RS-232 IN 9-
pin D-sub port on the second VS-162V unit.

9.1.2 Connecting Two Units without a Null-Modem Adapter

To connect two VS-162V units, without using a null-modem adapter:

1. Connect a flat cable

1

between the RS-232 OUT 9-pin D-sub port on the first

VS-162V unit and the RS-232 IN 9-pin D-sub port on the second VS-162V
unit.

2. On the second VS-162V unit, set DIP 7 ON (disabling null-modem adapter

use

2

9.1.3 Connecting to a 9-pin PC COM Port with a Null-Modem Adapter

).

To connect the 9-pin D-sub COM port of a PC to a VS-162V unit, using a
null-modem adapter
:

1. Connect a flat cable

1

between the 9-pin D-sub COM port of the PC and the

null-modem adapter that attaches to the RS-232 IN 9-pin D-sub port on the
VS-162V unit.

2. Set DIP 7 OFF (enabling null-modem adapter use

2

) on the VS-162V unit.

1 Straight one-to-one uncrossed connections with at least the 3 wires pins # 2, # 3 and # 5

2 See section 8
