MENU Commands
53
53
2. Press the TAKE button.
The MATRIX display shows the message:
Use OUTkey to configure
1: REPLY 2: No Reply
3. Press the OUT button 2.
The TAKE LED flashes and The displays show the messages:
Set serial port No reply
Press TAKE to execute Current:
Reply
4. Press the TAKE button again.
The displays show the messages:
Switcher response
changed
Current:
No reply
11.10 Setting the IR REMOTE Control
Set the IR REMOTE control to enable remote control of the VS-162V
16x16 Video Matrix Switcher, using the Kramer RC-IR2 Infrared Remote
Control Device
1
. Refer to the RC-IR2 Infrared Remote Control Device user
manual
2
Table 7 , for full details. and Table 8 summarize the setup and
operational commands.
Table 7: Summary of Basic RC-IR2 Setups
To execute this command: Press the following keys in this sequence:
Allocate the VS-162V to Group 12 SHIFT + GROUP + 12
Set the MACHINE # UNIT + # key
3
To enable IR REMOTE control (when set OFF), do the following:
(according to the VS-162V DIP-switch
settings)
1. Press the MENU button until reaching the IR REMOTE setting.
The MATRIX display shows the message:
IR REMOTE setting
yes -> TAKE, next -> MENU
2. Press the TAKE button.
The displays show the messages:
Outkey 1: InfraredREMOTE OFF
2: InfraredREMOTE ON
current:
remote OFF
1 After enabling the IR REMOTE control command, remotely control the VS-162V via the RC-IR2 remote control
transmitter pointed at the remote receiver on the VS-162V’s front panel (item 1 in Figure 1 )
2 You can download it from the Internet at this URL http://www.kramerelectronics.com/manuals.html
3 For example, press UNIT + # 1 if the VS-162V is set as MACHINE # 1
